| MOQ: | 1uite module or 1 unit cabinet |
| Price: | negotionable |
| Standard Packaging: | flightcase or Wooden case |
| Delivery Period: | 25-30days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 1000SQM/Month |
The AlisenLED Carbon Fiber Series
The AlisenLED Carbon Fiber Series of indoor LED video walls is a high-performance, versatile display solution designed for various installation needs. Here are its key features and benefits: Key Features:
1. Sleek & Lightweight Design
Advanced carbon fiber frames ensure durability while keeping the displays lightweight for easy handling and installation.
2. Versatile Installation Options ◦ Supports hanging, free-standing, and wall-mounted setups, making it ideal for different venue requirements.
3. Flexible Cabinet Sizes ◦ Available in 500×500mm and 500×1000mm configurations, allowing for custom display sizes and aspect ratios.
4. Quick & Easy Setup ◦ Designed for fast assembly, making it suitable for both fixed installations and temporary events.
5. High-Quality Visual Performance
Delivers bright, vibrant visuals with seamless image quality, perfect for corporate, retail, broadcast, and event applications.
Specification
| Carbon FiberP2.6 Indoor Rental Technical Parameter | |||||
| Product Name | Indoor P2.6 | ||||
| Basic Parameters | Pixel Configuration | SMD1515 1R1G1B | |||
| Pixel Pitch(W/H) | mm | 2.6 | |||
| Pixel Density | pixel/m2 | 148225 | |||
| Cabinet Size | mm | 500 x 500/500x1000 mm | |||
| Panel Resolution (W/H) | dots | 192 x 192 /192x385 dots | |||
| Weight | kg/m2 | 16/14kg | |||
| Optical Parameters | Brightness | cd/m2 | 800-1500 | ||
| Visual Angle | Horizontal | ° | 160 | ||
| Vertical | ° | 160 | |||
| Color Temperature | K | 3200～9300K Adjustable | |||
| Contrast | 8000:1 | ||||
| Process Performance Parameters | Refresh Rate | Hz | >3840 | ||
| Changing Rate | Hz | 60 | |||
| Processing Depth | bit | 14-16 | |||
| Color | 32768× 32768 × 32768 | ||||
| Driving Mode | Constant Current Driving | ||||
| Electrical Parameters | Power Supply | V | AC100~ 240V | ||
| Working Voltage | V | 5V DC | |||
| Average Power | w/m2 | 120-150 | |||
| Max Power | w/m2 | 400-500 | |||
| Other Parameters | Control Distance | m | CAT5 cable: <100m; Single Mode Fiber: <10000m | ||
| Lifespan | h | 100000 | |||
| Working Temperature | ℃ | -20 to +50 | |||
| Working Humidity | 10% ~ 95% | ||||
| Storage and Transportation Temperature | ℃ | -40 to +60 | |||
| Storage and Transportation Humidity | 10% ~ 95% | ||||
| Ingress Protection | IP30 | ||||
| Installation | Rental/Fixed | ||||
| Maintenance Way | Front/Rear | ||||
| Controll Mode | Synchronous control | ||||
| Signal Input Format | DVI / HDMI | ||||
| Operating System | Windows (7/8/10) | ||||
Ideal Applications:
• Corporate lobbies & boardrooms
• Retail stores & showrooms
• Broadcast studios & control rooms
• Exhibitions & trade shows
• Theaters & entertainment venues
Why Choose AlisenLED Carbon Fiber Series?
• Durability: Carbon fiber construction ensures long-lasting performance.
• Adaptability: Fits various installation environments with minimal effort
.• Professional Aesthetics: Ultra-slim design enhances visual appeal in any setting. This series is an excellent choice
for businesses and venues seeking a reliable, high-quality, and easy-to-install LED video wall solution.
|
|
